TELEFUNKEN TF39 Copperhead Deluxe Three-Pattern Large Diaphragm Microphone

$1,495.00

The phantom-powered TF6 features a beautifully open and detailed frequency response with exceptionally fast transient response, high SPL handling, and low self-noise.

SKU: TF39 Categories: ,
Description

Description

“The TF39 Copperhead Deluxe is an expansion of the “Copperhead” sound with the addition of a dual membrane K67-style capsule, allowing for 3-pattern selection between cardioid, omnidirectional, and figure-8. This added feature set gives the TF39 greater flexibility and options in the studio. Sonically and component-wise, the two microphones are otherwise the same.

The TF39 features a new old stock American-made 5654W vacuum tube, all-brass K67-style capsule, and a premium Swedish-made Lundahl output transformer. These components create a balanced frequency response and natural tonality, making the TF39 a trusty go-to choice.

Every TF39 Copperhead Deluxe microphone system comes with a multi pattern M 903 Power Supply, M 803 Tube Microphone Cable, ZC03



Type

Vacuum Tube Condenser

Polar Pattern Cardioid, Omnidirectional, Figure-8
Frequency Range 20 Hz – 20 kHz, ±3 dB
Power Source External Power Supply
Capsule TK67 – Center Terminated Large Diaphragm
Tube NOS GE 5654W
Transformer Lundahl LL1935
Sensitivity 17 mV/Pa, ±1 dB
THD at 1kHz, 1 Pa (Amplifier) < 0.3%
Output Impedance < 300 Ω
Maximum SPL (for 1% THD) 130 dB
S/N Ratio 87 dBA
Self Noise (Amplifier) 7 dBA
Dimensions 200 mm L x 46 mm Dia
Weight 650 g
Included Accessories Tube Mic Cable, Power Supply, Shock Mount, Stand Mount, Mic Sleeve, Carrying Case
Power Supply M 903 PSU
Cable M 803
Shockmount M 703, M 782
Case ZC03

Every TF39 Copperhead Deluxe microphone system comes with a fixed pattern M 903 Power Supply, M 803 Tube Microphone Cable, ZC03 Carry Case, M 703 Shock Mount, M 782 Stand Mount, and Microphone Sleeve.
